AI Isometric Game Maker — Build a Walkable 2.5D World in Your Browser

An AI isometric game maker takes a written scene description and gives back a playable 2.5D world: a diamond tile grid, a camera locked to a 45 degree yaw, props sorted from back to front, and a character you can send anywhere with a click. Neta Studio does this in the browser. You type the sentence, the composer places terrain and props on the grid, and you press Play. No engine install, no export step, no build pipeline.

The parts that normally eat a weekend are the parts already wired up: the 2:1 projection, the depth sort, and the screen-to-tile inverse transform behind click-to-move. What you actually control is the layout, the tile set, the character, the movement rules, and how far the camera is allowed to move.

One sentence → an isometric world

The composer is the first screen. One text field, a map size in tiles, and a tile size. You describe the scene the way you would describe it to a level designer, generate, and land in the editor with a diamond-grid world already assembled. The default is 64 by 64 tiles at 64 by 32 pixels per tile, which puts a full screen of world inside one orthographic camera with no zoom required.

What comes back is four layers. Ground stores one terrain id per tile and is merged into a single mesh, not one mesh per tile. Props sit on registered footprints: a 1x1 barrel, a 3x3 house, a 2x4 dock that has to touch a water edge. Entities are kept separate from props because they move and need pathfinding data. Lighting and fog sit on top and do not affect sort order.

The camera is set to a 45 degree yaw and a pitch that matches a 2:1 diamond exactly, which is atan(0.5), about 26.57 degrees, not the 30 degrees most tutorials quote. Projection is orthographic, so there is no perspective divide and a tile at the far edge of the map is the same pixel size as a tile at the near edge. Depth sorting is active before you ever press Play.

It picks terrain distribution, prop density per biome, and a palette that stays inside one atlas. More importantly it registers footprints, which is the thing that keeps occlusion correct later. If you ask for a harbour town you get docks, crates, and a water edge, but it will not know that the dock has to touch water unless you say so.

Repaint terrain with the brush, drag props from the library, and set spawn points. Anything with a rule attached, like a bridge that has to span a river, you place yourself. The composer gives you a starting layout, not a finished level.

The diamond grid and depth sorting, handled

An isometric tile is a square rotated 45 degrees and squashed to half height. With tileW = 64 and tileH = 32, the world-to-screen transform is sx = (x - y) * 32 and sy = (x + y) * 16. That is the entire projection. It is not a true isometric projection, it is dimetric at roughly 26.57 degrees, which is exactly why 2:1 diamonds land on whole pixels and a true 30 degree isometric grid does not. The 2:1 ratio is chosen because it foreshortens both axes equally and lets every sprite be drawn for a single camera angle.

Depth order under this projection is the painter's algorithm: draw the object with the smaller tileX + tileY first. That holds until two objects share a diagonal. A fence at (5, 3) and a character at (4, 4) both produce the key 8. Whichever order the sort returns draws on top, and if the sort is not stable the order flips between frames and the pair flickers at the seam. The second break is height. A sprite anchored at its center sorts by its middle pixel, so a 96 pixel lantern draws over a character standing in front of its base. Anchors belong at the bottom center of the sprite, on the tile the object occupies.

The third break is size. A 3x3 building sorted as one object with key 20 will draw over a character at (9, 12), key 21, even though that character is standing in front of the building's left column. The engine reads the registered footprint and slices anything larger than 1x1 into per-column strips, so the character passes in front of one column and behind the next. It is the same reason a long wall cannot be a single sprite.

Click-to-move on a real tile grid

This starts with the inverse of the projection. Take the pointer position, subtract the camera origin and any letterbox offset, then compute tileX = (sx / 32 + sy / 16) / 2 and tileY = (sy / 16 - sx / 32) / 2, then floor both. Get the sign wrong on the second term and the character walks to the mirror tile across the diamond center. That is the bug you will spend an afternoon on.

If the camera can rotate or move freely, do not cache that inverse. Cast a ray from the camera through the pointer, intersect the ground plane, and convert the world hit point to tiles with the same formulas. The raycast version is a few lines and survives every camera change.

Then validate. The clicked tile may hold a prop footprint, be water, be outside the map, or be unreachable. Clamp out-of-bounds coordinates, check the occupancy grid, and run A* over 8 neighbours with a diagonal cost of 1.414 and no corner cutting between two blocked tiles. Move in tiles per second rather than pixels per second, so speed stays constant when you change tile size. Walk through tile centers along a smoothed spline with an arrival radius of about 0.05 tiles, or the character stutters at every waypoint.

Isometric genres you can build

Four genres cover most isometric projects, and they differ in occupancy rules and in time, not in projection. A city builder lives on multi-tile footprints, a road network that has to connect, and a build mode that previews a footprint before placement. Tactics is turn-based, so pathfinding runs for many units at once and range highlighting is drawn straight onto the diamond grid. A dungeon crawler uses small maps and tight corridors, where per-column wall slicing matters most because the camera never moves. An action RPG is real-time, so steering, attack states, and animation blending matter more than pathfinding elegance.

What stays identical across all four: the 2:1 diamond, the sort key, the feet anchor, and the inverse transform on click. Switching genre mid-project changes occupancy rules and the update loop, not the renderer.

Play it now — in the browser

Every world here runs in the browser with no install and no export. The scene graph is Three.js, the renderer is WebGL2 with a WebGL1 fallback, and the map loads as merged ground geometry plus instanced props. You press Play and you are walking. Share the world and someone else is walking in it on their own machine, at the same 45 degree yaw.

On phones the same click path runs through pointer events, so a tap is a click. Tap targets are tiles, which means a slightly imprecise tap on a 1-tile prop still resolves to the right tile. Pinch zoom is off by default on maps under 32 tiles across because the 2:1 diamond is already legible at phone width. If frame rate drops, cut prop count before you cut map size; instancing helps more than deleting terrain.

Mini World is the small-map case: a compact diamond island, a handful of props, one character, click-to-move across the whole thing. It is the fastest way to watch ground merging and per-tile sorting behave, because you can see the entire map at once and there is nowhere for a bad sort key to hide.

The Cyclops' Island is the case where occlusion actually matters: tall props, wall columns, and a character that walks behind them. Watch a building corner as the character passes it. The strip in front draws over the character, the strip behind draws under it, and at no point does the character pop through the wall.

Agent Sprite Forge produces character sheets drawn for the isometric angle, with the pivot already at bottom center and the frame height matched to your tile height. Keep the camera at the default yaw and one sheet is enough. Enable camera rotation and you need a sheet per yaw step, because a sprite drawn for 45 degrees reads wrong at 90.

Walk into the world it belongs to

A sprite is a character with nowhere to stand. The last step is the one nobody else offers: take the sheet you just built and put it in a world someone can walk around in — a small island, a planet, a rainy street corner. Every world on this site was made from one written description and published as a page you can play.
