Tiled map editor · browser tab, no install

Tiled Map Editor Online — Paint a Map, Then Walk It

A tiled map is an index grid, not a painting: tile size, layer stack, autotile, collision. Decide those four once and a 48 × 30 level paints in minutes.

Foosha dock · play — Luffy on the quay he was just painted onto, market stalls and barrels around him.Katagiri courtyard · whole map — 48 × 30 at fit: paving, the practice lane, the drainage channel, planters under the windows.Hyrule Field · whole map — 48 × 30 at fit: castle stone, the stable paddock, the river down the east edge.Liyue · collision view — Every blocked cell in red — crates, railings, wall and water — 621 of 1,440 painted.
✦Tilemap
Make a browser tilemap editor for a Liyue harbour terrace with stone quays and a delivery lane — tileset palette, paint, autotile and collision brushes, three layers, play mode with a walking character. Open on a painted level.

No tiled-map skill in the catalog yet, so the prompt carries the spec: tileset palette, three index layers, autotile and collision brushes, play mode, JSON export.

Liyue Upper Terraces · editor — Opens on a painted level: 48 × 30 cells at 32 px, tileset and props left, layers right, minimap below.
Liyue Upper Terraces · editor — Opens on a painted level: 48 × 30 cells at 32 px, tileset and props left, layers right, minimap below.
Foosha Village Dock · editor — The dark build: palette rows, a 4 × 4 autotile mask, live counts — 715 blocked, 725 walkable.
Foosha Village Dock · editor — The dark build: palette rows, a 4 × 4 autotile mask, live counts — 715 blocked, 725 walkable.
Katagiri courtyard · autotile — Two grass patches dropped on paving; sixteen mask variants close their own corners.
Katagiri courtyard · autotile — Two grass patches dropped on paving; sixteen mask variants close their own corners.
Liyue · one grass stroke — Edges resolve from four neighbours as the stroke lands. No corner placed by hand, no seam.
Liyue · one grass stroke — Edges resolve from four neighbours as the stroke lands. No corner placed by hand, no seam.
Katagiri courtyard · collision brush — Red cells are 1s in the collision layer. Five cells painted, blocked count 352 → 360.
Katagiri courtyard · collision brush — Red cells are 1s in the collision layer. Five cells painted, blocked count 352 → 360.
Foosha dock · collision view — Sea, houses, stalls and crates blocked: 723 against 717 walkable on the painted dock.
Foosha dock · collision view — Sea, houses, stalls and crates blocked: 723 against 717 walkable on the painted dock.
Katagiri courtyard · detail hidden — Eye off on detail and every bench, planter and window leaves the map. Ground and collision stay.
Katagiri courtyard · detail hidden — Eye off on detail and every bench, planter and window leaves the map. Ground and collision stay.
Liyue Upper Terraces · play — Press Play and Xiangling walks the quays; water and railings stop her on the collision layer.
Liyue Upper Terraces · play — Press Play and Xiangling walks the quays; water and railings stop her on the collision layer.
Hyrule Field · play — Link on the road outside the stable at dusk. Click a walkable cell and he paths there.
Hyrule Field · play — Link on the road outside the stable at dusk. Click a walkable cell and he paths there.
LIVE PROOF

See the work live.

Open the work and use it here.

See the work live.Open in new tab
Want your own?Make My Own
PLAYABLE PROOF

This map is not a still.

Open the Liyue editor, paint a tile, then walk the result. It opens on the Upper Terraces — 1,440 tiles, 621 blocked, 819 walkable.

Liyue editorOpen in new tab
Want your own map?Make My Editor ↗

A level is data you can edit.

Neta Studio is an AI world builder — cast, places, art and playable scenes in one place. A tilemap is the smallest piece of that world that is still an editor: an index grid you paint, walk and export, with your own cast standing on it.

  • Cells, not brush strokes — Every path and crate is an integer in a layer, so a 48 × 30 map is a few thousand numbers you can undo, diff and export.
  • Autotile does the corners — A painted blob resolves its own edges and inner corners from four neighbours. You paint the shape; the tileset picks the tile.
  • Play is the test — Collision is a layer and Play is in the same tab. Walk the route, see which cell stops you, fix it, keep painting.

Questions? Answered.

Is this the same as Tiled?

No. Tiled is a desktop editor for .tmx projects. This runs in a browser tab: you paint, press Play and walk the level right there, then export the layers as JSON instead of opening another program to test.

Do I have to install anything?

No. The editor, the tileset and the level all load with the page. A mouse, a keyboard and a browser tab are the whole setup.

Can I open my existing TMX project?

Not read back. The export is JSON — width, height, tile size, tileset columns and three integer layers — which maps straight onto a TMX layer array when you move the level into Godot, Unity or Tiled.

What tile size should I use?

Pick one and never mix it. 16 px reads retro, 32 px is the safest for characters and props, 48 or 64 suit a wider camera. The palette and the grid have to agree, or sampling lands mid-tile.

How does autotiling work?

Each terrain carries 16 variants keyed by its four neighbours — outer corners, inner corners, straight edges and the fill. A painted blob picks its own tiles, so you never place a corner by hand.

Do I need three layers?

Ground is dense and holds the terrain. Detail is sparse and holds props, with 0 for empty. Collision is 1 or 0 per cell and it is what Play reads. Two layers is fine for a flat map; the third is what makes it walkable.

Can I use the export in Godot or Unity?

Yes. Every engine stores a tilemap as a grid of indices, which is exactly what the JSON export is. Re-point the tileset image and the layer arrays load.

Does it work on a phone?

It runs: palette and layers drop into a bottom sheet and the canvas takes the full width. Painting is precise with a mouse or a pen; on a phone it is better for checking a level than for drawing one.

Paint the map you keep sketching on paper.

Name the place. The editor, the tileset, three layers and a character who can walk the result come back with it.

×
